PVDF fluorine-carbon color-coated steel sheet

PVDF fluorine-carbon coating is the superb product among existing building coatings. As a recognized organic coating with the best protection function can protect metal building sheets from the damage and can preserve the beautiful color for decades. Up to now, PVDF fluorine-carbon coating has had a history of over 30 years for application to global buildings. Such buildings are still as good as new today. PVDF is polyvinylidene fluoride. The biggest electronegativity of fluorine atom can form very stable fluorine carbon bonds, and its molecules are unique. As a result, PVDF features superb stability, unique UV photolysis resistance and extraordinary insulation and mechanical performance.

I. Definition of fluorine-carbon coating sheet:

Fluorine-carbon coating sheet is the colored stove varnished metal sheet made by applying PVDF fluorine-carbon polyester coating to metal sheet for high-temperature baking.

II. Characteristics of the fluorine-carbon coating sheet:

1. It has superb stability and can keep the stability of various properties in acid/alkali and severely-polluted environments.
2. With the outstanding durability, fluorine-carbon coating sheet can preserve good color and gloss outdoors for 20 years.
3. With the extraordinary processing performance, coated colored sheets possess high toughness and impact resistance and enables post-embossing processing.

III. Key indicators of fluorine-carbon coating

　　Content of fluorocarbon resin in coating:≥70%

　　Specific gravity: 1.20±0.1kg/kg

　　Coating weight: 330㎡/kg (subject to 1um dry film)

　　Solid content: 42±2% (weight),38±2%(volume)

　　Packaging viscosity: 100~120s

　　PMT:249~254℃ (Peak Metal Temperature, referring to the peak temperature on the surface of band steel)

　　Salt spray test: >1000h

　　MEK: >150 times (MEK wiping)

　　T bending: 0~1T

　　Reverse impact: >9J

　　Lustrousness (60°): 15~40%

　　Pencil hardness: >F

PVDF Fluorine-Carbon Color-Coated Steel Sheet is a high-quality product offered by HNLF Steel. It is specifically designed to provide exceptional durability, weather resistance, and aesthetic appeal.

The PVDF coating on the steel sheet is made of polyvinylidene fluoride, which is a highly durable and weather-resistant material. This coating offers excellent protection against UV rays, moisture, and other environmental factors, making it suitable for both interior and exterior applications.

PVDF Fluorine-Carbon Color-Coated Steel Sheet is known for its outstanding color retention and vibrant appearance. The PVDF coating ensures that the colors remain vivid and fade-resistant, even in harsh weather conditions, providing long-lasting beauty and protection.

In addition to its exceptional aesthetics, PVDF Fluorine-Carbon Color-Coated Steel Sheet offers excellent durability. It exhibits high resistance to scratches, abrasions, and corrosion, ensuring long-term performance with minimal maintenance requirements.
